Self Cleaning Filter With Brush Type

Description & Working Principle Of Self Cleaning Filter With Brush Type

The raw liquid enters the filter through the liquid inlet. During the filtration process,the impurities in the water accumulate on the stainless steel

filter screen, and the innerlayer of impurities gradually accumulates.

①Automatic cleaning: When the filtration time reaches the set value, the automatic cleaning process will be started: electronic control system

Give a signal, the motor starts to work, the motor rotates to drive the drive shaft to rotate, the scraper removes the impurities accumulated on

the filter screen, and the motor stops working after the cleaning time reaches the set value. The blowdown valve is opened and blowdown begins.

②Manual cleaning: The motor runs continuously, driving the drive shaft to rotate, and the scraper continuously removes the impurities on the

filter screen. When the time set value is reached, the sewage valve is manually opened to start sewage.

③Pressure differential cleaning (optional): When the pressure difference between the liquid inlet and the liquid outlet reaches the set value,

the motor starts to work, the motor rotates to drive the drive shaft to rotate, and the scraper removes the impurities accumulated on the filter screen.

After the cleaning time reaches the set value , the motor stops working.

Features Of Self Cleaning Filter With Brush Type

1. High filtration accuracy, the minimum accuracy can reach 20 microns.

2. No disposable consumables are produced, saving consumable costs and environmental protection treatment costs.

3. High degree of automation, no need for manual cleaning, dual control of pressure difference and time, to achieve full automation of cleaning

4. Closed filtration to prevent leakage of hazardous materials, which is conducive to safe and efficient production.

Application Industry of Self Cleaning Filter With Brush Type

Water treatment,Paper making, petrochemical, sanitary, harmaceutical,paint, ink, grease, food andbeverage, etc.
